Computer graphics image of a WEC, developed by the Quantum Wave Microscopy Unit

The blades of this five-blade turbine are made of a soft material and they rotate on their axis when influenced by ocean waves—the diameter of the turbine is about 0.7 meters. The axis is attached to a permanent magnet electric generator, which is the part of the turbine that transforms the ocean wave energy into usable electricity. The ceramic mechanical seal protects the electrical components inside of the body from any saltwater leakage. This design allows the turbine to function for ten years before it need replacing.

The blades of this five-blade turbine are made of a soft material and they rotate on their axis when influenced by ocean waves—the diameter of the turbine is about 0.7 meters. The axis is attached to a permanent magnet electric generator, which is the part of the turbine that transforms the ocean wave energy into usable electricity. The ceramic mechanical seal protects the electrical components inside of the body from any saltwater leakage. This design allows the turbine to function for ten years before it need replacing.

Date:
20 September 2017

Copyright OIST (Okinawa Institute of Science and Technology Graduate University, 沖縄科学技術大学院大学). Creative Commons Attribution 4.0 International License (CC BY 4.0).

Download full-resolution image
